350U

Performance and versatility of high flow and pressure for a variety of portable, commercial equipment up to 3.0gpm and up to 1000psi.


Description

350U plunger pumps were custom designed for the pest control industry where pumps driven by gasoline engines are common. With powerful 12 VDC performance of 3gpm at 150psi, our pumps eliminate the noise, air pollution, carbon monoxide hazards, fuel costs, and maintenance issues of gas-powered systems.

You can expect precise application rates that help meet your regulatory and safety requirements because our pumps maintain performance at the nozzle for consistent output flow. Performance can be optimized to your application flow rates. Also available with 1hp AC induction motor. This pump is proudly made in the USA from aircraft-grade aluminum and stainless steel.


Specifications

Body
Hardcoat Aluminum
Plunger
Stainless Steel
Valves
Stainless Steel
Inlet Port
(2) - 3/8" NPT (F)
Discharge Port
(2) - 3/8" NPT (F)
Max Fluid Temp.(°F)
140

Features

1
2
3
350U-blog-header

Configurations

Model
350U-12VDC 30A
Max Pressure (PSI)
300
Open Flow (GPM)
3.00
Seals
NBR
Volts
12VDC
Amps
30
Performance Chart
View PDF
Dimensional Images
View PDF
CAD File
View STEP file
 100FC-12VDC
Flow Controller: 100FC-12VDC
Model
350U-12VDC 43A
Max Pressure (PSI)
500
Open Flow (GPM)
3.00
Seals
NBR
Volts
12VDC
Amps
43
Performance Chart
View PDF
Dimensional Images
View PDF
CAD File
View STEP file
 100FC-12VDC
Flow Controller: 100FC-12VDC
Model
350U-120/230VAC
Max Pressure (PSI)
1000
Open Flow (GPM)
3.00
Seals
NBR
Volts
120/230VAC
Amps
10/5
Performance Chart
View PDF
Dimensional Images
View PDF
CAD File
View STEP file
